Prima IV
Prima was born in the early 1990’s. Since then thousands have been delivered, faithfully serving in paragliding schools all over the world.
Probably the longest produced classic trainer – it is equally well suited for teaching free flying and perfect for entry level paramotoring.
Now this classic wing has been modernised once again – the 4th version of the wing has been released on the market. The wing is exactly the same as before, but now with Flexon™ batten system , pioneered by APCO – installed across L/E (today standard on entire APCO range).
Prima IV also features improved flare and adaptability for paramotor flying. The canopy is also more rigid (no tip movement), with redesigned, modern handling – direct and responsive in comparison with past designs.
The rest of Prima specifications remain the same. As always, produced from bomb proof, indestructible Gelvenor cloth combined with heavy duty lines, to ensure long lasting life.
Second generation Gelvenor cloth is much improved – as durable as ever, but significantly lighter without sacrificing any of its famous qualities (you will be surprised by how light it is) The direct benefit of the new Gelvenor is its contribution to even further improved launch and safety – making Prima IV equally well adapted for free flying schooling or paramotor training.
Many schools are amazed, unbelievably witnessing the years of service Prima IV can deliver. All this for a low price – specially designed to be affordable for all. As a schooling/entry level glider it is still the best investment on the market.
More Information
Technical Data
| PRIMA IV | 22 | 24 | 27 | 30 | 33 |
|---|---|---|---|---|---|
| Cells | 20 | 21 | 23 | 25 | 27 |
| Area [m2] | 22.5 | 23.9 | 26.7 | 29.4 | 32.14 |
| Area (projected) [m2] | 20.4 | 21.5 | 23.9 | 26.3 | 28.6 |
| Span [m] | 8.51 | 8.96 | 9.86 | 10.76 | 11.66 |
| Span (projected) [m] | 7.56 | 7.9 | 8.67 | 9.4 | 10.1 |
| Aspect Ratio | 3.22 | 3.36 | 3.65 | 3.94 | 4.2 |
| Aspect Ratio (projected) | 2.8 | 2.91 | 3.11 | 3.36 | 3.56 |
| Pilot Weight (all up) free flight [kg] | 50-65 | 60-78 | 70-90 | 80-100 | 95-120 |
| Pilot Weight (all up + paramotor unit) [kg] | 60-100 | 70-115 | 80-125 | 90-135 | 105-155 |
| Canopy Weight [kg] | 4.6 | 4.8 | 5.4 | 5.9 | 6.4 |
| Length of Lines on B [m] | 5.34 | 5.34 | 5.79 | 5.79 | 6.2 |
Performance
| V-min [km/h] | 19 |
|---|---|
| V-trim [km/h] | 31 |
| V-max [km/h] | 39 |
| Min Sink [m/s] at optimal wing loading | 1.4 |
Construction
The glider is made from tear resistant Ripstop Nylon cloth, which is P.U. coated to zero porosity and then siliconized to give the fabric high resistance to the elements. Different cloth is used for the top, bottom and ribs due to their different functions. The lines are made of superaramid covered with a polyester sheath for protection against UV, wear and abrasion. The bottom section of the brake lines is made of polyester because of its better mechanical properties. The karabiners that attach the lines to the risers are made of stainless steel.
| Material | Diameter [mm] | Strength [kg] | |
|---|---|---|---|
| Top | Super Aramid | 1.8 | 220 |
| Lower | Super Aramid | 1.8 | 220 |
| Brake Cascades | Dyneema | 1.1 | 95 |
| Steering Line | Polyester | 2.2 | 95 |
| Sail Cloth | 42 gr/m2 “Zero Porosity” Ripstop Nylon |
| Rib Reinforcement | FLEXON® batten system |
| Warranty | 3 years / 250 Hours |
In the Box
- Glider Backpack or light clinch bag
- Glider stuff bag
- Closing belt
- Riser sock
- Wind sock
- Warranty, stickers and repair kit
Manual
Characteristics
-
TAKE OFF
Perfect for Ground training and Training flights, the Prima IV has very easy and forgiving inflation and take-off characteristics.
-
LANDING
Low glide angle makes it easy to judge your landing approach, while the low approach speed, combined with long brake travel gives a super safe landing, even if the flare timing is misjudged.
-
INSTRUCTOR FEEDBACK
The Prima is a tank, indestructible. Probably more students train on this wing than any other training wing in the world! It is the only wing to use for ground handling and hill training.
-
CONSTRUCTION
Bomb proof!
The first certified paraglider with a Sharknose profile, released in 1992. Built from the most durable materials available, the Prima has stood the test of time. -
PRIMA IV
The perfect school training wing or a basic, straightforward trike paramotor wing.
Features
-
DSC
DSC – Double Siliconized Cloth
-
APP
Automatic Pressurising Profile
-
L/E FLEXON battens®
A system for improved launch, lighter weight, prolonged lifespan
-
NBM
Integral built-in neodymium brake magnets
Certification
| Size | Certification Type |
|---|---|
| 22 | None |
| 24 | CEN/AFNOR Standard |
| 27 | CEN/AFNOR Standard |
| 30 | CEN/AFNOR Standard |
| 33 | None |
Specifications
| Size | 22, 24, 27, 30, 33 |
|---|---|
| Color | Red, Turquoise, Yellow, Orange |
